Chapter 2 - Specification
2-8
3) CI-020~040-P2/4 (UL Open Type with installed UL Type 1 kit) and
CI-020~040-P6 (UL Open Type)


 

inches (mm)
Model W1 W2 W3 H1 H2 H3 D1 D2
Enclosure
Type
CI
-
020
-
P2/4
CI-020-P6
9.84
(250)
9.06
(230)
7.9
(200.8)
15.16
(385)
14.57
(370)
17.88
(454.2)
7.91
(201)
5.74
(146)
UL Type 1
IP20
CI
-
025
-
P2/4
CI
-
025
-
P6
9.84
(250)
9.06
(230)
7.9
(200.8)
15.16
(385)
14.57
(370)
17.88
(454.2)
7.91
(201)
5.74
(146)
UL Type 1
IP20
CI
-
030
-
P2/4
CI
-
030
-
P6
11.97
(
304
)
11.18
(
284
)
9
.
29
(
2
36
)
18.11
(
460
)
17.52
(
445
)
23.59
(
599
.2
)
9.21
(
234
)
6.98
(
177.5
)
UL Type 1
IP20
CI
-
040
-
P2/4
CI
-
040
-
P6
11.97
(304)
11.18
(284)
9
.
29
(2
36
)
18.11
(460)
17.52
(445)
23.59
(599.2)
9.21
(234)
6.98
(177.5)
UL Type 1
IP20
