4.1.3 Programming the VFD Parameters
The navigation through VFD parameters is similar to the book reading process. Finding a desired
parameter group is similar to finding a right page in the book- flip pages one after another. Finding a
desired parameter in the parameter group is the same as finding a desired line on the book page- scroll
Up or Down.
1) Press [MODE] key until the desired parameter group is displayed.
2) Press [] or [] keys to scroll to the desired parameter. If you know the desired parameter number,
you can set its number in the first parameter #00 “Jump code” of any parameter group (except SET
and DRV groups) and after pressing [ENT] key display will show that parameter.
3) Press [ENT] key to enter the programming mode, which is indicated by a flashing cursor.
4) Press [] or [] keys to change parameter selection or [SHIFT] key to move the cursor to the right
to the desired digit.
5) Press [] or [] keys to change the digit in numerical parameter value.
6) Press [ENT] key to finish programming for this parameter. The flashing cursor disappears.
Note: 1.Some parameters cannot be changed during run mode and a flashing cursor will not appear. If Parameter Lock
function activated in parameter FU2-94, all parameters are protected from programming.
2. If two or more parameters are set to the same function, the “Overlap” message can be displayed.
Example: Changing Motor FLA setting from 9.6A to 9.9A.
The VFD display shows parameter DRV-00 in the DRIVE group. Press [MODE] key several times
until display shows parameter SET-00 in parameter group SET.
[MODE] . . . . [MODE]
Press [] key three times to go to parameter SET-03 Motor FLA. (Some parameter groups have parameter
#00 with Jump Code # that can be used to jump to any parameter directly).
Press [ENT] key to start parameter programming and flashing cursor will appear
on the left side of the FLA number. If [] or [] key is pressed, the number
will be changed to a minimum or maximum possible value for this parameter.
Press [SHIFT] key to move the cursor to a digit “6” and press [
]
key three
times to change this digit to “9”.
Press [ENT] key and flashing cursor will disappear and VFD exits a
programming mode.
Press [
]
or [
]
key to go to another parameter in SET group or [MODE] or
[SHIFT] key to go to another program group.
