CDC-2000
操作手冊
Operational Manual
E-stop and the button will arise, then to push key can turn on the
power of the controller.
1.6. Motor Operational Keys:
: Start motor, LED Light located on the upper left of the button is on if the
upper left would be off. The motor can
’
t be stopped under automatic mode.
: Stop motor, push this button to stop the motor, and LED light on the upper
left would be off. The motor can
’
t be stopped under automatic mode.
1.7. The Function of Operational Keys on screen:
MANUAL OPERATION MODE 4 / 5 11:25
MOLD NO. NOZZLE T1 T2 T3 T4 T5 T6 Tc
YYYYYYYY AA% BBB CCC DDD EEE FFF GGG HHH
aaaaaaaaaaa
Sbb Pcc Bdd bbb ccc ddd eee fff ggg hhh
EEEE.Emm
BATCH NO. : WWWWW
GOOD PART NO. : XXXXX
OOOO.Omm PPPP.Pmm QQQQ.Qmm SSSkg/cm
2
RRRrpm
SET
M
畫面
01
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
04/08/13
7
