CDC-2000
操作手冊
Operational Manual
1.7.1. After the start-up system Menu test is finished, Menu switches to Operational Menu (01),
The two bottom lines which have the yellow background are the Menu names that are
often used. Press the fast-selection keys can switch to the required Menu. For example,
if you press
on Menu (01) as shown above, Menu switches to Mold close and
Mold open setting Menu. The Operational functions of the keys are shown below
:
: Power on button for controller.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: Quick menu switchover, used to switch to menu shown at the screen bottom.
: 1. Switch to operational Menu.
2. When on the operational Menu, This button is used to switch the menu
shown at the bottom of the screen.
04/08/13
8
