1 Operational Manual
2.39.2 Output Node Monitoring of Computer for High-Pressure Cylinder
OUTPUT MONITORING PAGE
NO. CONTENT NO. CONTENT NO. CONTENT
PENU. DOOR CLOSE 61 PNEU. DOOR OPEN 62 NOZZLE FORWARD
63 INJECTIN 64 FEEDING 65 DECOMPRESSION
66 NOZZLE BACKWARD MOLD OPEN/CLOSE 68 EJECTOR FORWARD
EJECTOR BACKWARD 70 BOOST CLAMPING 71 CORE 1 IN
72 CORE 1 OUT 73 UNSCREW-IN 74 UNSCREW-OUT
75 THINNER 76 THICKER 77 ACCUM. PRESSED
78 ACCUM. INJECTION 79 PNEU.DOOR SLOW 80 AIRBLOW AT END
81 AIRBLOW AT OPENING 82 FEEDING AT OPENING 83 CORE 2 IN
84 CORE 2 OUT 85 LOCK-UP CLOSE 86 LOCK UP OPEN
87 BOOST 88 SPARE 89 SAPRE
90 SAPRE 91 SYSTEM FUNCTION 92 SPARE
93 SPARE 94 SPARE 95 SPARE
96 SPARE 97 SPARE 98 SPARE
99 SPARE 100 SPARE 101 SPARE
102 SPARE 103 SPARE 104 SPARE
105 SPARE 106 SPARE 107 SPARE
108 SPARE 109 SPARE 110 SPARE
111 SPARE H. MOTOR START-UP H. MOTOR RUNNING
114 ALARM 115 LUBRICATION 116 HEATER BAND
117 SPARE 118 SPARE 119 SPARE
Menu 41
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
60
67
69
112 113
This menu provides customers to check the output signal from CDC-2000, when the
code number turns to red, it means this output signal is
“
ON
”
. The descriptions
are as below:
No. Content Description
６０
Spare Spare
６１
Spare Spare
６２
Nozzle Forward Carriage Forward Output
６３
Injection Injection Output
６４
Feeding Plasticizing Output
６５
Decompression Decompression Output
６６
Nozzle Backward Carriage Backward Output
６７
Mold Open / Close
Output
Mold Open /Close Output
６８
Ejector Forward Ejector Forward Output
６９
Ejector Backward Ejector Backward Output
04/08/13
120
