Chen Hsong CDC-2000 - Page 127

1 Operational Manual
No. Content Description
７０
Boost Clamping Carriage Forward Output
７１
Core 1 In
Core 1 In Output。
７２
Core 1 Out
Core 1 Out Output。
７３
Mold Screw In
Mold Screw Forward Output。(Optional)
７４
Mold Screw-Out
Mold Screw Backward Output。(Optional)
７５
Spare Spare
７６
Spare Spare
７７
Full-Oil Value Full-Oil Value Output for Mold-Opening
７８
High pressure relief Leakage Pressure Output for Mold-Opening
７９
Spare Spare
８０
Airblow at End Airblowing Output After Mold Opening
８１
Airblow at Opening Airblowing Output After Mold Setting Position
８２
Spare Spare
８３
Core 2 In Core 2 In (Optional)
８４
Core 2 Out Core 2 Out (Optional)
８５
Pos. Cylinder Forward After completion of injection at auto mode, this output will “ON”.
８６
Pos. Cylinder Backward Output signal for robot to take part out, when mold opens, this
output will “ON”.
８７
Boost
When purchasing ＤＳor double pump, this is aux. Flow rate
output.
８８
Lock-Up Close
８９
Super Fast Mold-Closing
９０
Clamp Cyl. Close Clamping Low Pressure Output
９１
System Used System Saving Confirmation Output.
９２
Blank
９３
Blank
９４
Blank
９５
Blank
９６
Blank
９７
Blank
９８
Blank
９９
Blank
１００
Blank
No. Content Description
１０１
Blank
１０２
Blank
１０３
Blank
１０４
Blank
１０５
Blank
04/08/13
121
