TIMER REVIEW MONITORING PAGE 2
DESCRIPTION SET TURE DESCRIPTION SET TURE
SPARE T32
AAAA.A ????.? SPARE T33 BBBB.B ????.?
SPARE T34
CCCC.C ????.? SPARE T35 DDDD.D ????.?
ABNOR MD OP DELAY
EEEE.E ????.? SPARE T37 FFFF.F ????.?
COUNT MD THICK
GGGG.G ????.? NOZZLE STROKE CHEC HHHH.H ????.?
SPARE T40
IIII.I ????.? SPARE T41 JJJ.JJ ???.??
SPARE T42
KKKK.K ????.? SPARE T43 LLLL.L ????.?
EJECT BUFFER TIME
MMM.MM ???.?? ABNORMAL SHUT-OFF NNNN.N ????.?
ATUO CLA END BUF
OOOO.O ????.? AUTO OP END BUF TI PPPP.P ????.?
MOTOR START-UP
QQQ.QQ ???.?? SPARE T49 RRRR.R ????.?
DECOM END DELAY
SSS.SS ???.?? CLAMP END. DELAY TTTT.T ????.?
SPECIAL FUNC
UUU.UU ????.? CLAMP CYL. DELAY VVV.VV ???.??
SPARE T54
WWWW.W ????.? CLA CYL.O. DELAY XXXX.X ????.?
Q.M.CYL.O DELAY
YYY.YY ???.?? MOLD OPEN TIME ZZZ.ZZ ???.??
M.THICK DELAY
aaa.aa ???.?? UNSCREW END DELAY bbb.bb ???.?
FEEDING END DELAY
ccc.cc ???.?? SPARE T61 ddd.dd ???.??
CORE END DELAY
eee.ee ???.?? 1 SEC TIMER fff.ff ???.??
Menu39B
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
3.5 “ 009 Barrel Temperature is Below the Setting Value “
(A) When thermal switch selects
“
close
”
or
“
warmth keeping
”
or
“
the barrel
‘
s
temperature is lower than setting value
”
, when intending to do injection,
decompression and plasticizing, the warning message will appear.
(B) Remedy:
a) Thermal switch selects
“
open
”
b) To do injection and decompression until the barrel
‘
s temperature is reached the
setting value.
3.6 “013 Large Cylinder Stroke Exceeds the Limit”
(A) Stroke of high-pressure cylinder exceeds the max. stroke, pump shut off.
(B) Remedy:
a) Check stroke protection L.S. Input 14.
b) When the alarm appear, the pump motor will be shut off, all operations are not
