1 Operational Manual
allowed. Press and simultaneously to release it, press to
start pump than press to open mold until the message disappears.
c) Adjust the mold height.
3.7 “014 Oil Level Is Too Low In Lubrication Oil Tank”
(A) When lubrication counter is up, but the oil level is too low (Input 25 on)
(B) Remedy: Refill the lubrication oil.
LUBRICATION SETTING
TOGGLE SYSTEM LUBRICATION AT EVERY
GGGGG CYCLES
NEXT LUBRICATION AT KKKKK CYCLE LATER
LUBRICATIN TIME HHHH.H SEC
LUBRICATIN MONITORING TIME
IIII.I SEC
GREASE LUBRICATION AT EVERY JJJJJ CYCLES (BY MANUAL)
NEXT LUBRICATION AT LLLLL CYCLE LATER
GREASE LUBRICATION ATALARM RESET
RESET
Menu 10
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
3.8 “015 Clamping Stroke Is Not Finished” “
(A) Split nut did not open completely (Input 19 off) and high-pressure cylinder did
not activate while intending to do injection or plasticizing is impossible.
04/08/13
163
