1 Operational Manual
the stroke checking time (Tim 53) of high-pressure cylinder in menu 39.
(B) Remedy:
a) Check the opening end and closing end signal (Input 19, Input 12).
b) Check the high-pressure directional control valve.
c) Modify stroke check time Tim 53 on Menu 39A.
TIMER REVIEW MONITORING PAGE 1
DESCRIPTION SET TURE DESCRIPTION SET TURE
INJECTION TIME
AAAA.A ????.? COOLING TIME BBBB.B ????.?
INTERMISSION
CCCC.C ????.? CYCLE TIME DDDD.D ????.?
EJECT PAUSE
EEEE.E ????.? SPARE 05 FFFF.F ????.?
LOW PR.-ALARM
GGG.GG ???.?? FEEDING DELAY HHH.HH ???.??
FEED OPEN ALARM
IIII.I ????.? NOZ. FORWARD FAST JJJ.JJ ???.??
NOZ. FOR. STROKE
KKK.KK ???.?? NOZZLE BACKWARD LLL.LL ???.??
CORE 1 IN
MMMM.M ????.? CORE 1 OUT NNNN.N ????.?
CORE 2 IN
OOOO.O ????.? CORE 2 OUT PPPP.P ????.?
FAST UNSCREW-IN
QQQQ.Q ????.? SLOW UNSCREW-IN RRRR.R ????.?
FAST UNSCREW-OUT
SSSS.S ????.? SLOW UNSCREW-OUT TTTT.T ????.?
3STEP UNSCR BACK
UUUU.U ????.? HOLDING PR.1 VVVV.V ????.?
HOLDING PR.2
WWWW.W ????.? HOLDING PR.3 XXXX.X ????.?
EJECTION DELAY
YYYY.Y ????.? AIRBLOW T. OPENING ZZZZ.Z ????.?
AIRBLOW DELAY OPEN
aaa.aa ???.?? AIRBLOW TIME OPEN bbb.bb ???.??
LUBRICATION TIME
ccc.cc ???.?? LUBRICATION ALARM ddd.dd ???.??
ACCUMLATOR ALARM
eee.ee ???.?? ACCUM. PRESSURIZED fff.ff ???.??
Menu39
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
3.24 “039 Check Limit Switch of Mold Screw”
(A) Conditions:
a) Mold Screw L.S. did not finish its task at given time, warning message will appear.
b) Mold Screw out L.S. signal
“
input 37
”
and in signal
“
input 36
”
are on
simultaneously.
c) Mold Screw out L.S.
“
input 37
”
is not on (OFF) while intending to do ejector
forward.
(B) Remedy:
a) Check the circuit of Input 37 and Input 36.
b) Modify the stroke check time (Mold screw in JJJJ.J, Mold screw out QQQQ.Q)and
04/08/13
169
