CDC-2000
操作手冊
Operational Manual
2.5.3.2 Move cursor to the desired parameter. Key in desired digits and press to
complete a correction．
Code descriptions of Menu (03) for carriage cylinder are as follows:
A) AA : Speed setup of carriage cylinder for mold-closing.
B) BB : Pressure setup of carriage cylinder for clamping.
C) ee : Back pressure setup of carriage cylinder for clamping. (optional function)
D) CCC.C : End-position setup of carriage cylinder for clamping.
E) DD : Speed setup of carriage cylinder for low pressure clamping.
F) EE : Pressure setup of carriage cylinder for low pressure clamping.
G) ff : Back pressure setup of carriage cylinder for low pressure clamping. (optional
function)
H) FFFFF : End-position setup of carriage cylinder for low pressure clamping, it
’
s
also the beginning position for high pressure clamping.
I) vvv.v : Motion inspection time setup of carriage cylinder for low pressure
clamping.
J) GG : Hydraulic velocity setup of carriage cylinder for mold closing confirmation.
K) HH : Hydraulic pressure setup of carriage cylinder for mold closing confirmation.
L) gg : Back pressure setup of carriage cylinder for mold closing confirmation.
(optional function)
M) IIIII : Lower stroke-limit position setup of carriage cylinder for mold closing,
the position setup is within 20p, don
’
t change it arbitrarily.
N) iii.i : Motion time of clamping.
O) The position setup condition of carriage cylinder for clamping stroke change is:
RRR.Rmm ≧ WWWW.Wmm ≧CCCC.Cmm ≧ FFFFFp ≧ IIIIIp.
2.5.3.3. Motion Descriptions of Clamping:
There are three steps of clamping for carriage cylinder:
A) Move the mold speedily by carriage cylinder.
B) Move the mold in low pressure and low speed stroke to protect the mold. The
setting of
“
DD
”
and
“
EE
”
has to be less than 40%, and the less the better. At
this step, use
“
vvv.v
”
time to check the motion. If anything is wrong,
“
072 mold
cleaning
”
alarm will appear.
C) Confirm the mold closing of carriage cylinder. The machine belongs to direct
hydraulic clamping structure. Before high pressure clamping, make sure there
is a mold on it and the mold is close. When the mold is closed, the pressure
of carriage cylinder will go up. When the pressure reaches the setting of (Input
11), the mold closing is confirmed and the carriage cylinder finishes its stroke.
04/08/13
26
