CDC-2000
操作手冊
Operational Manual
one of four modes listed below and push to complete the selection.
Code descriptions:
C.a) Core-pull off: Core-in 2 off.
C.b) Before mold-closing: Core-in 2 before molds close.
C.c) During mold-closing: Core-in 2 is executed during mold closing at
“
NNNN.N
”
C.d) position.
C.e) After mold-closing: Core-in 2 is executed after mold-closing.
D) NNNN.N: Core-in 2 is executed while the position is reached in mold-closing.
E) SSS.S: Time setup of core-in 2.
F) TTTTTT: Position selection for core-in 2 is used to
or for one of
two modes listed below and press
to complete the selection.
Code selections are as follows:
F.a) Select
“
timer
”
to confirm the distance.
F.b) Select
“
Limit switch
”
as a confirmation of core-in 2 by connecting to Input 6
while the checking time
“
SSS.S
“
reached.
G) UU: Velocity setup for core-in 2.
H) VV: Pressure setup for core-in 2.
I) OOOOOOOOOO :operation selection of core-out 2. Press or for one of
four modes listed below and push
to complete the selection.
Code descriptions for function selection are as follows:
I.a) Not used: Don
’
t apply the function of core-out 2.
I.b) Before mold-opening: Core-out 2 before molds open.
I.c) During mold-opening: Core-out 2 during mold opening at the set position
“
PPPP.P
”
.
I.d) After mold-opening: Core-out 2 after molds open.
J) PPPP.P: Core-out 2 is executed when mold-opening moves to this position.
K) WWW.W: Time setup for core-out 2.
L) XXXXXX : Feedback options of core-out 2. Press
or for one of two modes
listed below and push
to complete the selection.
Code descriptions for function selection are as follows:
L.a) Select
“
Timer
”
to confirm the completion of core-out 2. Time is set at WWW.W
“
,
and the program timer code is
“
Tim 15
”
.
L.b) Select
“
Limit switch
”
as a confirmation of the completion by connecting limit
switch to Input 7. The set time of
“
WWW.W
“
acts as timer control.
04/08/13
45
