Chen Hsong CDC-2000 - Page 51

CDC-2000
操作手冊
Operational Manual
04/08/13
47
L) MMM.M : Time setup for Mold Screw out/slow, program timer code
“
Tim 17
”
。
M) NNNNNN : Feedback options for Mold Screw-out. Press either or to
make a pick among three molds, and push
to complete the selection. Code
descriptions for function selection as follows:
M.a) Select
“
Timer
”
to confirm the completion of Mold Screw out. Time for unscrew-
out/fast is set at
“
JJJ.J
”
, then Mold Screw out/slow is set at
“
MMM.M
”
.
M.b) Select
“
limit switch
“
as spare function selection.
M.c) Select
“
counter
“
as a confirmation by Mold Screw turns.
“
GGGGG
”
Total turns for
mold screw in and out.
“
EEEEE
”
Mold Screw fast-turn counts, internal program
code Cnt 5.
“
FFFFF
”
Mold Screw slow-turn counts, internal program code Cnt 6.
Counting signal is keyed in to Input 30。
2.9.2. Mold Screw Out Setup
Move cursor to set parameter of Mold Screw out 3. Key in desired digits and press to
complete a correction. Code descriptions of Menu (07) as follows:
A) OO :Speed setup for Mold Screw out/fast.
B) PP : Pressure setup for Mold Screw out/fast.
C) RR : Speed setup for Mold Screw out/slow.
D) SS : Pressure setup for Mold Screw out/slow.
E) CCCCCCCCCC :Mode options for Mold Screw out. Press either
or for one
of four modes listed below, and push
to complete the selection. Code
descriptions for function selection are as follows:
E.a) Mold Screw-out Off.
E.b) Before mold-closing: Mold Screw out before closing molds.
E.c) During mold-closing: Mold Screw out during mold closing at
“
DDDD.D
”
set
position.
E.d) After mold-closing: Mold Screw out after mold close.
F) DDDD.D : Mold Screw out when molds close at this position.
G) QQQ.Q : Time setup for Mold Screw out/fast, program timer code
“
Tim 18
”
.
H) TTT.T : Time setup for Mold Screw out/slow, program timer code
“
Tim 19
”
.
I) UUUUUU :Feedback options for Mold Screw out. Press either or to make
a pick among three molds, and push
to complete the selection. Code
descriptions for function selection are as below:
I.a) Select
“
Timer
”
to confirm the completion of Mold Screw out. Time for Mold Screw
out/fast is set at
“
QQQ.Q
”
, and then Mold Screw out/slow is set at
“
TTT.T
”
.
I .b) Select “Limit Switch” as spare function selection.
