1 Operational Manual
1.c) Select
“
counter
”
setting, use mold screw turning number as a confirmation
of motion.
“
GGGGG
”
is the number of mold screw turning back and forth.
“
EEEEE
”
is the counter number setting of mold screw fast turning, internal
program
’
s code is Cnt 5.
“
FFFFF
”
is the counter number setting of mold screw
slow turning, internal program code is Cnt 6. Mold screw counter signal is
transferred to Input 30 of computer.
2.9.3 Mold Screw Setup
Move cursor to set parameter of Mold Screw out 3. Key in desired digits and press
to complete a correction. Code descriptions of Menu (07) are shown below:
A) XX: speed setup for Mold Screw out 3.
B) YY: pressure setup for Mold Sscrew out 3.
C) VVVVVVVVVV: mode options for Mold Screw out 3. Press either or to
make a pick between 2 modes listed below and push
to complete the
selection.
Code descriptions for function selection as follows:
C.a) Mold Screw out 3 not used.
C.b) During mold-close: Mold Screw out 3 during mold opening at
“
DDD.D
”
position.
D) ZZZ.Z: Time setup for Mold Screw out 3, the program timer code
“
Tim 20
”
.
E) bbbbbb: Feedback options for Mold Screw out 3. Press either
or to
make a selection among three modes, and push
to complete it. Code
descriptions for function selection as follows:
E.a) Select
“
timer
”
to confirm the completion.
E.b) Select
“
limitswitch
”
as spare function selection.
E.c) Select
“
counter
”
as a confirmation by Mold Screw turns.
“
aaaaa
”
is the count step for Mold Screw out 3. and the internal program code
Cnt 7.
Counting signal is keyed in to
Input 30.
04/08/13
46
