2.9.4 Sequence Diagram of Mold Screw
Directional
Valve (in)
Parameter
Switching
Setup
Status
Directional
Valve (out)
Screw-in Screw-out
OO% PP% RR% SS%
Fast-
counts
(EEEE)
Mold Screw Counting Flow Chart
Parameter
Switching
Setup
HH% II% KK% LL%
Fast-counts
(EEEE)
Total-counts(GGGG)
Total-out (GGGG)
Slow-counts
(FFFF)
Slowcounts
(FFFF)
Directional
Value (in)
Parameter
Switching
setup
Status
Directional
Valve(out)
Screw-in Screw-out
OO% PP% RR% SS%
Fast-times
(QQQ.Q)
Mold screw Times Flow Chart
Parameter
Switching setup
HH% II% KK% LL%
Fast-times
(JJJ.J)
Slow-times
(TTT.T)
Slow-times
(MMM.M)
