1 Operational Manual
B) xx.xx: Display the time of injection.
C) wwww.w: Display the time of feeding.
D) ZZZ.Z : Plasticizing end-position setup. It acts as a 100% benchmark for injection
stroke. Key in desired digits and press for a correction. If desired digits
are keyed in and
is pressed, the position set value per section will be
re-calculated according to its percentage.
E) zzz.z: Time setup for from injection 1 to injection 6, computer program timer code
“
Tim 00
”
. Holding pressure stroke will follow when injection stroke is finished.
F) AA: Speed setup for injection 1.
G) BB: Pressure setup for injection 1.
H) CCC.C: End-position setup for injection 1. Key in desired digits and press
to complete a correction. If desired digits are keyed in and
are pressed,
stroke setting of injection 1 will be recalculated according to its position set
value.
I) DD: Stroke setting of injection 1. Plasticizing end position equals 100%. Key in
desired digits and press to complete a correction. If desired digits are
key in and
is pressed, the position set value of injection 1 will be
recalculated according to its percentage.
J) EE: Speed setup for injection 2.
K) FF: Pressure setup for injection 2.
L) GGG.G: End-position setup for injection 2. Key in desired digits and press
to
complete a correction. If desired digits are keyed in and
are pressed,
stroke setting of injection 2 will be recalculated according to its position set
value.
M) HH: Stroke setting of injection 2. Plasticizing end-position equals 100%. Key in
desired digits and press
to complete a correction. If desired digits are
keyed in and
are pressed, the position set value of injection 2 will be
re-calculated according to its percentage.
N) II: Speed setup for injection 3.
O) JJ: Pressure setup for injection 3.
P) KKK.K: End-position setup for injection 3. Key in desired digits and press
to complete a correction. If desired digits are keyed in and
are pressed,
04/08/13
60
