1 Operational Manual
2.30 Temperature Curve of TC
TC TEMP. CURVE SET : HIGH : LOW :
500
400
300
200
100
Menu 30
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
This curve shows the TC temperature trend:
: Blue line is to indicate the deviation setting for high-temperature.
: Red line is to indicate the setting value of temperature.
: Light-blue line is to indicate the deviation setting for low-temperature.
: White line is to indicate the practical temperature.
