4.3.3. B Mode
Intended Use:
B-mode is intended to provide two-dimensional images and measurement capabilities concerning the
anatomical structure of soft tissue. Press B -knob to enter into B mode. Rotate B-knob to adjust B gain.
Fig. 4-6 B Mode
4.3.4. Dual Mode
In B mode, press key .System will and display the current image at the left side of the screen, Press
