Chison Q9 - Ao;Lv; Lvot; MV

Q9 Digital Color Doppler Ultrasound System
88
FS
Fractional shortening
FS = (LVIDd
-
LVIDs)/LVIDd
8. AO/LV
<<Item to be measured>>
Meas. item
name
Description
Meas. method
Root of aorta
Root of aorta
diameter
Refer to "Distance
Measurement
(Distance)".
LVIDd
Light ventricular short
-
axis diameter at end diastole
Refer to "Distance
Measurement
(Distance)".
<<Item to be calculated>>
Calc. item
name
Description [Unit]
Calc. formula
AO/LV
AO/LVIDd
AO/LVIDd
9. LVOT
<<Item to be measured>>
Meas. item
name
Description
Meas. method
LA Diam
left ventricular outflow tract
diameter
Refer to
"Distance
Measurement
(Distance)"
<<Item to be calculated>>
Calc. item
name
Description [Unit]
Calc. formula
Area
left ventricular outflow tract
area
Refer to "area"
10. MV
<<Item to be measured>>
Meas. item
name
Description
Meas. method
MV D
iam
Mitral valve diameter
Refer to "Distance
Measurement
(Distance)"
MVArea
Mitral valve area
Refer to "area
Measurement
