gain can adjust sensitivity of overall images (brightness). Rotate the knob of B mode could adjust B gain after
the B light is on. The gain will be increased if rotate clockwise; the gain will be decreased if rotate contra.
Adjust range is from 0 to 255. TGC will influence on each other between gain adjustment and TGC
adjustment.
5 TGC
TGC with 8 adjustable slides: Slide the set of slider bars can change the depth gain of 2D images.
TGC returns signal amplifier to correct for the attenuation caused when adding depth. TGC balance the image
and make the density of echo uniformly distributed in images. Similarly the enlargement of every sliding
channel area is also different.
The range of TGC will redistribute according to the new depth while depth is changing.
Move the slide bar Left/Right can reduce/increase TGC.
6 Image magnification （ZOOM -knob ）
Press ZOOM- knob, press UPDATE-key to choose the size of ROI box ,and then press UPDATE-key again to
choose the position. Press ENTER- key can realize multiple enlargements. Press EXIT-key or ZOOM knob to
exit operation.
4.3.19. Image Optimization of M mode
Shortcut menu adjustment：
（rotate）
Speed
Adjust scanning
speed
1，2，3，4 adjustable. adjust clockwise, the numerical increase and
adjust anticlockwise,the numerical decrease. Adjust range: 1.
(press)
Layout Adjust layout UD, LR
4.3.20. Color Flow Map(CFM) Mode image optimization
Soft menu adjustment：
To Next Page
