Video Pattern Generator 2238 User’s Manual
1-2
1.2.2 A223801 Display Port Signal Module
A223801 DISPLAYPORT SIGNAL MODULE
Video
Pixel rate range
25 MHz~2.4GHz
Resolution
8Kx4K@30Hz (1Port)
8Kx4K@60Hz (2Port)
3D Format
Frame/Field Sequential
Stacked Frame
Pixel Interleaved
Side-by-side
Signal compliant
DisplayPort v1.4 Specification
Video signal type
RGB / YCbCr
Sampling mode
RGB 4:4:4 / YCbCr 4:4:4 or 4:2:2 or 4:2:0
Color depth
6 / 8 / 10 / 12 / 16 bits per component
Color space
RGB / ITU-R BT.601 / ITU-R BT.709 / ITU-R BT.2020
HDCP
HDCP V1.3 / HDCP V2.2
Main Link Data Rate
1.62 / 2.7 / 5.4 / 8.1 (HRB3) Gbps per lane
Lane Count
1 / 2 / 4 / 4 + 4 Lanes
Pre-emphasis
0dB / 3.5dB / 6dB / 9.5dB selectable
Swing level
400mV/600mV/800mV/1200mV selectable
Audio
Channel
2 Channel (L-PCM)-Internal ; 8 Channel
(AC3/DTS)-External;
8 Channel HBR-audio
Sample rate
32 , 44.1 , 48 , 88.2 , 96 , 176.4 , 192KHz , +/- 1000ppm
Bits per sample
16 / 20 / 24 Bits
Amplitude
-90.3 ~ 0.0 dBFS / -138.47 ~ 0.0 dBFS programmable
Frequency
10 Hz ~ 20 KHz, 1 Hz/step
CONNECTOR
DisplayPort
DisplayPort x 2
S/PDIF
S/PDIF In x 1 (Coaxial)
1.2.3 A223802 HDMI Signal Module
A223802 HDMI SIGNAL MODULE
Video
Pixel rate range
600 MHz Max. ( TMDS CLK : Max. 300MHz)
Resolution
4Kx2K@60Hz (1 Port)
8Kx4K@60Hz (4 Port)
3D Format
Frame packing
Field alternative
Line alternative
Side-by-Side (Full)
L + depth
L + depth + graphics + graphics-depth
Top-and-Bottom
Side-by-Side (Half)
Frame sequential
Line-by-Line
Checkerboard
Dual Pipe 3D
