Chroma 2238 - Appendix A: Default Timings List

Appendix A Default Timings List
A-1
Appendix A Default Timings List
The VPG has built in approximately 800 sets of timings; however, the actual amount of timing
is varied with the signals supported by each model. The timings are classified as the table
shown below.
No.
Classification
1 ~ 100
Chroma 22xx / 23xx Series default Timing
101 ~ 130
TV Timing
131 ~ 200
SD/HDTV Timing
201 ~ 300
VESA Analog Timing
301 ~ 500
VESA CVT Timing
501 ~ 600
VESA Digital Timing
601 ~ 800
CTA-861–G Timing
801 ~ 850
PC Timing
851 ~ 900
SPWG Panel Timing
901 ~ 1000
DisplayPort – VESA Timing
1000 ~1200
DisplayPort – CVT Timing
1200 ~ 1300
DisplayPort Timing
1301 ~ 1400
3D Timing
1401 ~ 1500
Chroma 3G SDI Timing
1501 ~ 1600
DiiVA Timing
1601 ~ 2000
Reserved
2001 ~ 5000
User Storage
The timing no. listed in gray indicates it is invalid now, and will be supported
in the future.
