Overview
1-3
Support timing
CEA-861-F / CTA-861-G
Pixel repetition
1~10
Signal compliant
HDMI v2.0a Specification
Video signal type
RGB / YCbCr
Sampling mode
RGB 4:4:4 / YCbCr 4:4:4 or 4:2:2 or 4:2:0
Color depth
24 / 30 / 36 / 48 @ RGB & YCbCr
Color space
RGB / ITU-R BT.601 / ITU-R BT.709 /
xvYcc(IEC61966-2-4)/SYCC/AdobeRGB/AdobeYCC
/ ITU-R BT.2020
HDCP
HDCP 1.4 / HDCP V2.2
HDR
HDR 10
E-EDID
Version 1.3
Read / Write / Compare / Edit / Analysis
Audio
Channel
8 Channel (FL / FR / RL / RR / FC / LFE / RLC / RRC)
Sample rate
32 , 44.1 , 48 , 88.2 , 96 , 176.4 , 192KHz +/- 1000ppm
Bits per sample
16 / 20 / 24 Bit
Amplitude
-90.3 ~ 0.0 dBFS / -138.47 ~ 0.0 dBFS programmable
Frequency
10 Hz ~ 20 KHz, 1 Hz/step
ARC output
S/PDIF (Coaxial)
CONNECTOR
HDMI
HDMI Type A 19 Pin x 4
S/PDIF
S/PDIF In x 1 , S/PDIF Out x 1 (Coaxial)
1.2.4 A223803 Analog Signal Module
A223803 ANALOG SIGNAL MOUDULE
ANALOG
Pixel rate range
0.5 MHz ~ 300 MHz
3D Format
Frame sequential
Video signal
R, G, B (75 ohms)
Video level
0 ~ 1.0V, 1 mV/step
White level
0 ~ 1.2V, 1 mV/step
Black level
7.5 IRE / 0 IRE programmable
Sync level
0 ~ 0.5V, 1 mV/step
Sync on green
On / Off programmable
Rise/fall time
1.6nS (typical) , 2.0nS (maximum)
Separate sync
Hs / Vs / Xs
Video Format
R, G, B / RS-343A / RS-170 / VESA
Y, R-Y, B-Y
Y, Pb, Pr / ITU601, ITU709, RP177, SMPTE 240M
EDID
Version 1.3
Read / Write / Compare / Edit / Analysis
Signal compliant
VSIS v1.1
TV
Video format
NTSC (443 / M / J), PAL (BDGHI / M / 60 / N / Nc),
SECAM
Subcarrier accuracy
± 50 HZ
3D Format
Frame packing
Top-and-Bottom
