Chroma 2238 User Manual

Appendix A Default Timings List
A-23
TIMING 1001-1200 DisplayPort- CVT Timing
DP Timing
Timing
Timing Name
Pixel Rate (M)
Htotal
Hdisplay
Hbp
Hsw
Hf (K)
Vtotal
Vdisplay
Vbp
Vsw
Vf
HSync
VSync
H:Vsize
Bit rate
Lane
1001
1002
1003
DP-640x480-75 (CVT)
30.75
816
640
88
64
37.684
504
480
17
4
74.769
ON(-)
ON(+)
4:3
1.62
1
1004
DP-640x480-85 (CVT)
35.00
816
640
88
64
42.892
507
480
20
4
84.600
ON(-)
ON(+)
4:3
1.62
1
1005
1006
DP-800x600-50 (CVT)
30.75
992
800
96
72
30.998
621
600
14
4
49.916
ON(-)
ON(+)
4:3
1.62
1
1007
DP-800x600-60 (CVT)
38.25
1024
800
112
80
37.354
624
600
17
4
59.861
ON(-)
ON(+)
4:3
1.62
1
1008
DP-800x600-75 (CVT)
49.00
1040
800
120
80
47.115
629
600
22
4
74.905
ON(-)
ON(+)
4:3
1.62
1
1009
DP-800x600-85 (CVT)
56.75
1056
800
128
80
53.741
633
600
26
4
84.898
ON(-)
ON(+)
4:3
2.7
1
1010
DP-800x600-60-RB (CVT)
35.50
960
800
80
32
36.979
618
600
12
4
59.837
ON(+)
ON(-)
4:3
1.62
1
1011
DP-1024x768-50 (CVT)
52.00
1312
1024
144
104
39.634
793
768
18
4
49.980
ON(-)
ON(+)
4:3
1.62
1
1012
DP-1024x768-60 (CVT)
63.50
1328
1024
152
104
47.816
798
768
23
4
59.920
ON(-)
ON(+)
4:3
2.7
1
1013
DP-1024x768-75 (CVT)
82.00
1360
1024
168
104
60.294
805
768
30
4
74.900
ON(-)
ON(+)
4:3
2.7
1
1014
DP-1024x768-85 (CVT)
94.50
1376
1024
176
104
68.677
809
768
34
4
84.892
ON(-)
ON(+)
4:3
1.62
2
1015
DP-1024x768-60-RB (CVT)
56.00
1184
1024
80
32
47.297
790
768
16
4
59.870
ON(+)
ON(-)
4:3
2.7
1
1016
DP-1280x960-50 (CVT)
83.00
1680
1280
200
128
49.405
991
960
24
4
49.853
ON(-)
ON(+)
4:3
2.7
1
1017
DP-1280x960-60 (CVT)
101.25
1696
1280
208
128
59.699
996
960
29
4
59.939
ON(-)
ON(+)
4:3
1.62
2
1018
DP-1280x960-75 (CVT)
130.00
1728
1280
224
136
75.231
1005
960
38
4
74.857
ON(-)
ON(+)
4:3
2.7
2
1019
DP-1280x960-85 (CVT)
148.25
1728
1280
224
136
85.793
1011
960
44
4
84.859
ON(-)
ON(+)
4:3
2.7
2
1020
DP-1280x960-60-RB (CVT)
85.25
1440
1280
80
32
59.201
988
960
22
4
59.920
ON(+)
ON(-)
4:3
2.7
1
1021
DP-1400x1050-50 (CVT)
100.00
1848
1400
224
144
54.113
1083
1050
26
4
49.965
ON(-)
ON(+)
4:3
1.62
2
1022
DP-1400x1050-60 (CVT)
121.75
1864
1400
232
144
65.317
1089
1050
32
4
59.978
ON(-)
ON(+)
4:3
2.7
2
1023
DP-1400x1050-75 (CVT)
156.00
1896
1400
248
144
82.278
1099
1050
42
4
74.867
ON(-)
ON(+)
4:3
2.7
2
1024
DP-1400x1050-85 (CVT)
179.50
1912
1400
256
152
93.881
1105
1050
48
4
84.960
ON(-)
ON(+)
4:3
2.7
2
1025
DP-1400x1050-60-RB (CVT)
101.00
1560
1400
80
32
64.774
1080
1050
24
4
59.948
ON(+)
ON(-)
4:3
1.62
2
1026
DP-1600x1200-50 (CVT)
131.50
2128
1600
264
168
61.795
1238
1200
31
4
49.915
ON(-)
ON(+)
4:3
2.7
2
1027
DP-1600x1200-60 (CVT)
161.00
2160
1600
280
168
74.537
1245
1200
38
4
59.869
ON(-)
ON(+)
4:3
2.7
2
1028
DP-1600x1200-75 (CVT)
204.75
2176
1600
288
168
94.095
1255
1200
48
4
74.976
ON(-)
ON(+)
4:3
1.62
4
1029
DP-1600x1200-85 (CVT)
235.00
2192
1600
296
168
107.208
1262
1200
55
4
84.951
ON(-)
ON(+)
4:3
2.7
4
1030
DP-1600x1200-60-RB (CVT)
130.25
1760
1600
80
32
74.006
1235
1200
29
4
59.924
ON(+)
ON(-)
4:3
2.7
2
1031
DP-1920x1440-50 (CVT)
192.25
2592
1920
336
200
74.171
1484
1440
27
4
49.980
ON(-)
ON(+)
4:3
1.62
4
1032
DP-1920x1440-60 (CVT)
233.50
2608
1920
344
208
89.532
1493
1440
46
4
59.968
ON(-)
ON(+)
4:3
2.7
4
1033
1034
DP-1920x1440-60-RB (CVT)
184.75
2080
1920
80
32
88.822
1481
1440
35
4
59.974
ON(+)
ON(-)
4:3
1.62
4
1035
DP-2048x1536-50 (CVT)
219.00
2768
2048
360
216
79.118
1583
1536
40
4
49.980
ON(-)
ON(+)
4:3
2.7
4
1036
DP-2048x1536-60 (CVT)
267.25
2800
2048
376
224
95.446
1592
1536
49
4
59.954
ON(-)
ON(+)
4:3
2.7
4
1037
DP-2048x1536-60-RB (CVT)
209.25
2208
2048
80
32
94.769
1580
1536
38
4
59.980
ON(+)
ON(-)
4:3
1.62
4
1038
1039
DP-1280x1024-50 (CVT)
88.50
1680
1280
200
128
52.679
1057
1024
23
7
49.838
ON(-)
ON(+)
5:4
2.7
1
1040
DP-1280x1024-60 (CVT)
109.00
1712
1280
216
136
63.668
1063
1024
29
7
59.895
ON(-)
ON(+)
5:4
2.7
2
1041
DP-1280x1024-75 (CVT)
138.75
1728
1280
224
136
80.295
1072
1024
38
7
74.902
ON(-)
ON(+)
5:4
2.7
2
1042
DP-1280x1024-85 (CVT)
159.50
1744
1280
232
136
91.456
1078
1024
44
7
84.839
ON(-)
ON(+)
5:4
2.7
2
1043
DP-1280x1024-60-RB (CVT)
91.00
1440
1280
80
32
63.194
1054
1024
21
7
59.957
ON(+)
ON(-)
5:4
1.62
2
1044
DP-1280x768-50 (CVT)
65.25
1648
1280
184
128
39.593
793
768
15
7
49.929
ON(-)
ON(+)
15:9
2.7
1
1045
DP-1280x768-60 (CVT)
79.50
1664
1280
192
128
47.776
798
768
20
7
59.870
ON(-)
ON(+)
15:9
2.7
1
