Chroma 2238 User Manual

Appendix A Default Timings List
A-33
TIMING 1401-1422 3G SDI Timing
3G SDI Timing
Timing
Timing Name
Pixel Rate (M)
Htotal
Hdisplay
Hbp
Hsw
Hf (K)
Vtotal
Vdisplay
Vbp
Vsw
Vf
HSync
VSync
H:Vsize
1401
SDI_SD_480I
13.500
858
720
57
62
15.734
262
240
15
3
59.94
ON(-)
ON(-)
4:3
1402
SDI_SD_576I
13.500
864
720
69
63
15.625
312
288
19
3
50.00
ON(-)
ON(-)
4:3
1403
SDI_HD_720P60
74.250
1650
1280
220
40
45.000
750
720
20
5
60.01
ON(+)
ON(+)
16:9
1404
SDI_HD_1080I60
74.250
2200
1920
148
44
33.750
562
540
15
5
60.00
ON(+)
ON(+)
16:9
1405
SDI_HD_720P50
74.250
1980
1280
220
40
37.500
750
720
20
5
50.01
ON(+)
ON(+)
16:9
1406
SDI_HD_1080I50
74.250
2640
1920
148
44
28.125
562
540
15
5
50.00
ON(+)
ON(+)
16:9
1407
SDI_HD_1080P30
74.250
2200
1920
148
44
33.750
1125
1080
36
5
30.00
ON(+)
ON(+)
16:9
1408
SDI_HD_1080P25
74.250
2640
1920
148
44
28.125
1125
1080
36
5
25.00
ON(+)
ON(+)
16:9
1409
SDI_HD_1080P24
74.250
2750
1920
148
44
27.000
1125
1080
36
5
24.00
ON(+)
ON(+)
16:9
1410
SDI_HD_1080I59
74.175
2200
1920
148
44
33.715
562
540
15
5
59.94
ON(+)
ON(+)
16:9
1411
SDI_HD_720P59
74.175
1650
1280
220
40
44.954
750
720
20
5
59.94
ON(+)
ON(+)
16:9
1412
SDI_HD_1080P23
74.175
2750
1920
148
44
26.972
1125
1080
36
5
23.98
ON(+)
ON(+)
16:9
1413
SDI_HD_1080P29
74.175
2200
1920
148
44
33.715
1125
1080
36
5
29.97
ON(+)
ON(+)
16:9
1414
SDI_3GA_1080P50
148.500
2640
1920
148
44
56.250
1125
1080
36
5
50.00
ON(+)
ON(+)
16:9
1415
SDI_3GA_1080P59
148.350
2200
1920
148
44
67.431
1125
1080
36
5
59.94
ON(+)
ON(+)
16:9
1416
SDI_3GA_1080P60
148.500
2200
1920
148
44
67.500
1125
1080
36
5
60.00
ON(+)
ON(+)
16:9
1417
SDI_3GB_1080P50
148.500
2640
1920
148
44
56.250
1125
1080
36
5
50.00
ON(+)
ON(+)
16:9
1418
SDI_3GB_1080P59
148.350
2200
1920
148
44
67.431
1125
1080
36
5
59.94
ON(+)
ON(+)
16:9
1419
SDI_3GB_1080P60
148.500
2200
1920
148
44
67.500
1125
1080
36
5
60.00
ON(+)
ON(+)
16:9
1420
SDI_3GB_D_1080P50
148.500
2640
1920
148
44
56.250
1125
1080
36
5
50.00
ON(+)
ON(+)
16:9
1421
SDI_3GB_D_1080P59
148.350
2200
1920
148
44
67.431
1125
1080
36
5
59.94
ON(+)
ON(+)
16:9
1422
SDI_3GB_D_1080P60
148.500
2200
1920
148
44
67.500
1125
1080
36
5
60.00
ON(+)
ON(+)
16:9
1423
SDI_HD_1080_PSF30
74.250
2200
1920
148
44
33.750
562
540
15
5
60.00
ON(+)
ON(+)
16:9
1424
SDI_HD_1080_PSF29
74.175
2200
1920
148
44
33.715
562
540
15
5
59.94
ON(+)
ON(+)
16:9
1425
SDI_HD_1080_PSF25
74.250
2640
1920
148
44
28.125
562
540
15
5
50.00
ON(+)
ON(+)
16:9
1426
SDI_HD_1080_PSF24
74.250
2750
1920
148
44
27.000
562
540
15
5
48.00
ON(+)
ON(+)
16:9
1427
SDI_HD_1080_PSF23
74.175
2750
1920
148
44
26.972
562
540
15
5
47.9
ON(+)
ON(+)
16:9
1428
1429
1430
1431
1432
1433
1434
1435
1436
1437
1438
1439
1440
1441
1442
1443
1444
1445
1446
1447
1448
1449
1450
1451
1452
1453
1454
1455
1456
1457
1458
1459
1460
1461
1462
1463
