Chroma 2238 User Manual

Video Pattern Generator 2238 User’s Manual
B-54
939
3D.Depth.Stick
940
Reserved.
941
C-1080-SSH-OO
The 1920x1080 side-by-side (Half) and
SUB-SAMPLING MODE=OO 3D motion
image test pattern need to use this timing
format to output image.
A motion CHROMA LOGO is flying from
the screen end to the front. The original
depth of field will become bulged. When it
reaches the set position, the text will
rotate to see depth of field and bulge
effect.
942
S-1080-SSH-OO
The 1920x1080 side-by-side (Half) and
SUB-SAMPLING MODE=OO 3D motion
image test pattern need to use this Timing
format to output image.
The central spiral column is used as a
fulcrum with a revolving ball surrounding
the column. When the ball moves, the
user can obviously feel the depth of field
difference as positioned before, behind
and surrounding the column.
943
C-1080-SSH-OOX
The 1920x1080 side-by-side (Half) and
SUB-SAMPLING MODE=OOX 3D motion
image test pattern needs to use this
timing format to output image.
944
S-1080-SSH-OOX
The 1920x1080 side-by-side (Half) and
SUB-SAMPLING MODE=OOX 3D motion
image test pattern need to use this timing
format to output image.
945
C-1080-TB-OO
The 1920x1080 top and bottom and
SUB-SAMPLING MODE=OO 3D motion
image test pattern need to use this timing
format to output image.
