Operation
SWEEP MODE: The audio sweep has RISING, FALLING and DUAL modes for
selection.
RISING: The frequency changed from low to high.
FALLING: The frequency changed from high to low.
DUAL: The frequency changed by cycling from low to high and then high to low.
SWEEP MIN FREQ.: It edits the minimum frequency of Audio SWEEP ranged from 10 to
20000 Hz; 1Hz/Step.
SWEEP MAX FREQ.: It edits the maximum frequency of Audio SWEEP ranged from 10
to 20000 Hz; 1Hz/Step.
SWEEP MIN FREQ < SWEEP MAX FREQ.
SWEEP CYCLE: It edits the SWEEP TIME range (1.0~5.0 sec) to set the frequency
change time from low to high.
The FL (sync with Analog Audio L), FR (sync with Analog Audio R), LFE, FC, RL, RR,
RLC and RRC eight channels can be set respectively for audio.
When CHANNEL COUNT is set to 2CH, the LFE, FC, RL, RR, RLC and
RRC will be hidden from view.
