3.2 Parts and Controls
The following labeled diagrams illustrate the terms used in this manual to describe parts
and controls of the microplate reader. More details on the operation of each feature are
provided in Section 4-Operating Procedures.
3.2.1 Parts of the Instrument
Figure 3.2.1-1 Front of Instrument
Figure 3.2.1-2 Door open, tray out
A) Door
B) Indicator
light
B
A
A) Tray out
(extended)
B) Door open
A
B
