5.3.4 Test Results Tab
Features of the Test Results Tab are described in the table below.
Figure 5.3.4-1 Test Results Tab
Feature: Description: Item No.:
Layout
Area
Indicates the location of patient samples,
reagents, and pertinent assays. For more
information on a particular substance, highlight
it with the mouse cursor. For example:
1
List Use the ‘Highlight by Name/ID’ drop down menu
to highlight a patient, or use ‘Highlight by Assay’
drop down menu to highlight by type of assay. A
list of all of the assays will display. The Current
Step that is running displays to the right of the
drop down menus.
2
1
2
3
5
4
