ChroMate™ ChroMate™ Operator’s Manual Doc. 4300 Rev. E 77
Error Code(s)/Problem: Solution:
101 Invalid filter count of
%d, re-trying
102 Calibration Data
Checksum Failure
103 EEPROM not
acknowledging
104 Unable to detect filter
wheel home
105 Timeout positioning
filter wheel
Counted filters found to be other than 4 or 6, contact
customer service
Internal checksum doesn’t match, contact customer
service
EEPROM didn’t acknowledge command, contact
customer service
Contact customer service
Contact customer service
201 Extra movement of
(%d) needed at home
202 Plate did not return
home
203 Mech Test1 had %d
errors during %d
passes
204 Mech Test2 had %d
errors during %d
passes
205 Mech Test3 had %d
errors during %d
passes
Assumed position did not return carrier to home,
contact customer service
Plate did not return home after 20 seconds
Door in/out test had errors, check mechanism
movement
Plate incremental positioning tests had errors, check
mechanism movement
Plate drift check had errors, check mechanism
movement
206 InchesPerStep not in
range, %8.6
301 Pot %d, wiper %d,
Setting %d returned
%d (not 24)
302 Pot %d, wiper %d – not
ack
303 Pot %d, wiper %d – not
ack
401 Lamp voltage low,
ch(%d) Filt %d(%s)
<%1.3f volts
Rerun FE() command, check plate for sticking, check
plate holes
Contact Customer Service
Contact Customer Service
Contact Customer Service
Contact Customer Service
