5�6�3�8�- Modbus TCP (Switch) communications expansion modules
The screen in Figure 242, is a screen that displays the information of the Modbus TCP (Switch)
communications module.
Figure 242: Information screen of the Modbus TCP ( Switch ) module (TCP communications)�
This screen shows how the TCP communications of the module are congured.
>
>
>
<
<
<
varh
8
Back
Main
menu
TCP
Figure 243: Modbus TCP ( Switch ) module menu�
Use the keys and to select the different options.
To conrm the selection, press the key .
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
172
CVM-A1000 - CVM-A1500
Instruction Manual
