● When programming the decimals:
Here you program the number of decimals that the digital input will have.
.● When programming the meter factor:
The energy meter factor is the number of times the value of the digital input will be increased
for each impulse detected by said input.
5�7�18�3�- Conguration of digital inputs, logic state mode.
After selecting the conguration of an input in logic mode, you must select the input that you
want to congure in this mode:
Digital input 1.
Digital input 2.
When selecting the input to congure with the key (Figure 306), you can program the input
logic.
Figure 306: Digital inputs conguration screen (logic state mode).
The parameter selected is indicated in white.
The following options appear in the lower area:
214
CVM-A1000 - CVM-A1500
Instruction Manual
