The following options appear in the lower area:
>
<
>
>
>
>
>
<
<
<
<
<
1
>
<
>
<
Conguration
values
Previous
Next
Conrm
and save
Delete
parameter
Back
Main
menu
Delete
character
Figure 311: Setup menu: BACnet protocol�
Use the keys and to select the different options.
To conrm the selection, press the key .
● When programming the transmission speed, Baud Rate, the conguration values are:
, ... The possible transmission speeds: 9600, 19200, 38400, 57600, 76800
or 115200�
● When programming the MAC:
Here you have to program the MAC address.
Maximum value: 127.
Minimum value: 0.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the Device ID:
Maximum value: 4194303.
Minimum value: 0.
218
CVM-A1000 - CVM-A1500
Instruction Manual
