● When programming the ID:
The ID is the peripheral number assigned to the device in the Modbus network.
Maximum value: 255.
Minimum value: 0.
● When programming the transmission speed, Baud rate:
, ... The possible transmission speeds: 9600, 19200, 38400, 57600, 76800
or 115200�
● When programming the parity:
Even parity, Odd parity, No parity.
● When programming the number of stop bits:
, Possible numbers of stop bits: 1 or 2�
5�7�19�2�- Conguration parameters, BACnet protocol.
When selecting the BACnet communications protocol, Figure 310, you can program the
following parameters:
 The transmission speed, Baud Rate.
 The MAC.
 The Device ID.
Figure 310: Integrated communications conguration screen (BACnet protocol).
The parameter selected is indicated in white.
217
Instruction Manual
CVM-A1000 - CVM-A1500
