Table 37 (Continuation) : Modbus memory map: current energy variables�
Parameter Symbol
Address
1
(33)
2
(33)
Active energy generated LIII kWh LIII (-) 559-55A 55B
Inductive reactive energy generated L1 kvarhL L1 (-) 55C-55D 55E
Inductive reactive energy generated L2 kvarhL L2 (-) 55F-560 561
Inductive reactive energy generated L3 kvarhL L3 (-) 562-563 564
Inductive reactive energy generated LIII kvarhL LIII (-) 565-566 567
Capacitive reactive energy generated L1 kvarhC L1 (-) 568-569 56A
Capacitive reactive energy generated L2 kvarhC L2 (-) 56B -56C 56D
Capacitive reactive energy generated L3 kvarhC L3 (-) 56E-56F 570
Capacitive reactive energy generated LIII kvarhC LIII (-) 571-572 573
Reactive energy generated L1 kvarh L1 (-) 574-575 576
Reactive energy generated L2 kvarh L2 (-) 577-578 579
Reactive energy generated L3 kvarh L3 (-) 57A-57B 57C
Reactive energy generated LIII kvarh LIII (-) 57D-57E 57F
Apparent energy generated L1 kVAh L1 (-) 580-581 582
Apparent energy generated L2 kVAh L2 (-) 583-584 585
Apparent energy generated L3 kVAh L3 (-) 586-587 588
Apparent energy generated LIII kVAh LIII (-) 589-58A 58B
Tariff 2
Active energy consumed L1 kWh L1 58C-58D 58E
Active energy consumed L2 kWh L2 58F-590 591
Active energy consumed L3 kWh L3 592-593 594
Active energy consumed LIII kWh LIII 595-596 597
Inductive reactive energy consumed L1 kvarhL L1 598-599 59A
Inductive reactive energy consumed L2 kvarhL L2 59B -59C 59D
Inductive reactive energy consumed L3 kvarhL L3 59E-59F 5A0
Inductive reactive energy consumed LIII kvarhL LIII 5A1-5A2 5A3
Capacitive reactive energy consumed L1 kvarhC L1 5A4-5A5 5A6
Capacitive reactive energy consumed L2 kvarhC L2 5A7-5A8 5A9
Capacitive reactive energy consumed L3 kvarhC L3 5AA-5AB 5AC
Capacitive reactive energy consumed LIII kvarhC LIII 5AD-5AE 5AF
Reactive energy consumed L1 kvarh L1 5B0-5B1 5B2
Reactive energy consumed L2 kvarh L2 5B3-5B4 5B5
Reactive energy consumed L3 kvarh L3 5B6-5B7 5B8
Reactive energy consumed LIII kvarh LIII 5B9-5BA 5BB
Apparent energy consumed L1 kVAh L1 5BC-5BD 5BE
Apparent energy consumed L2 kVAh L2 5BF-5C0 5C1
Apparent energy consumed L3 kVAh L3 5C2-5C3 5C4
Apparent energy consumed LIII kVAh LIII 5C5-5C6 5C7
Active energy generated L1 kWh L1 (-) 5C8-5C9 5CA
Active energy generated L2 kWh L2 (-) 5CB-5CC 5CD
Active energy generated L3 kWh L3 (-) 5CE-5CF 5D0
Active energy generated LIII kWh LIII (-) 5D1-5D2 5D3
Inductive reactive energy generated L1 kvarhL L1 (-) 5D4-5D5 5D6
Inductive reactive energy generated L2 kvarhL L2 (-) 5D7-5D8 5D9
Inductive reactive energy generated L3 kvarhL L3 (-) 5DA-5DB 5DC
232
