Table 37 (Continuation) : Modbus memory map: current energy variables�
Parameter Symbol
Address
1
(33)
2
(33)
Inductive reactive energy generated LIII kvarhL LIII (-) 5DD-5DE 5DF
Capacitive reactive energy generated L1 kvarhC L1 (-) 5E0-5E1 5E2
Capacitive reactive energy generated L2 kvarhC L2 (-) 5E3-5E4 5E5
Capacitive reactive energy generated L3 kvarhC L3 (-) 5E6-5E7 5E8
Capacitive reactive energy generated LIII kvarhC LIII (-) 5E9-5EA 5EB
Reactive energy generated L1 kvarh L1 (-) 5EC-5ED 5EE
Reactive energy generated L2 kvarh L2 (-) 5EF-5F0 5F1
Reactive energy generated L3 kvarh L3 (-) 5F2-5F3 5F4
Reactive energy generated LIII kvarh LIII (-) 5F5-5F6 5F7
Apparent energy generated L1 kVAh L1 (-) 5F8-5F9 5FA
Apparent energy generated L2 kVAh L2 (-) 5FB-5FC 5FD
Apparent energy generated L3 kVAh L3 (-) 5FE-5FF 600
Apparent energy generated LIII kVAh LIII (-) 601-602 603
Tariff 3
Active energy consumed L1 kWh L1 604-605 606
Active energy consumed L2 kWh L2 607-608 609
Active energy consumed L3 kWh L3 60A-60B 60C
Active energy consumed LIII kWh LIII 60D-60E 60F
Inductive reactive energy consumed L1 kvarhL L1 610-611 612
Inductive reactive energy consumed L2 kvarhL L2 613-614 615
Inductive reactive energy consumed L3 kvarhL L3 616-617 618
Inductive reactive energy consumed LIII kvarhL LIII 619-61A 61B
Capacitive reactive energy consumed L1 kvarhC L1 61C-61D 61E
Capacitive reactive energy consumed L2 kvarhC L2 61F-620 621
Capacitive reactive energy consumed L3 kvarhC L3 622-623 624
Capacitive reactive energy consumed LIII kvarhC LIII 625-626 627
Reactive energy consumed L1 kvarh L1 628-629 62A
Reactive energy consumed L2 kvarh L2 62B -62C 62D
Reactive energy consumed L3 kvarh L3 62E-62F 630
Reactive energy consumed LIII kvarh LIII 631-632 633
Apparent energy consumed L1 kVAh L1 634-635 636
Apparent energy consumed L2 kVAh L2 637-638 639
Apparent energy consumed L3 kVAh L3 63A-63B 63C
Apparent energy consumed LIII kVAh LIII 63D-63E 63F
Active energy generated L1 kWh L1 (-) 640-641 642
Active energy generated L2 kWh L2 (-) 643-644 645
Active energy generated L3 kWh L3 (-) 646-647 648
Active energy generated LIII kWh LIII (-) 649-64A 64B
Inductive reactive energy generated L1 kvarhL L1 (-) 64C-64D 64E
Inductive reactive energy generated L2 kvarhL L2 (-) 64F-650 651
Inductive reactive energy generated L3 kvarhL L3 (-) 652-653 654
Inductive reactive energy generated LIII kvarhL LIII (-) 655-656 657
Capacitive reactive energy generated L1 kvarhC L1 (-) 658-659 65A
Capacitive reactive energy generated L2 kvarhC L2 (-) 65B -65C 65D
Capacitive reactive energy generated L3 kvarhC L3 (-) 65E-65F 660
