Table 37 (Continuation) : Modbus memory map: current energy variables�
Parameter Symbol
Address
1
(33)
2
(33)
Capacitive reactive energy generated LIII kvarhC LIII (-) 661-662 663
Reactive energy generated L1 kvarh L1 (-) 664-665 666
Reactive energy generated L2 kvarh L2 (-) 667-668 669
Reactive energy generated L3 kvarh L3 (-) 66A-66B 66C
Reactive energy generated LIII kvarh LIII (-) 66D-66E 66F
Apparent energy generated L1 kVAh L1 (-) 670-671 672
Apparent energy generated L2 kVAh L2 (-) 673-674 675
Apparent energy generated L3 kVAh L3 (-) 676-677 678
Apparent energy generated LIII kVAh LIII (-) 679-67A 67B
Total
Active energy consumed L1 kWh L1 67C-67D 67E
Active energy consumed L2 kWh L2 67F-680 681
Active energy consumed L3 kWh L3 682-683 684
Active energy consumed LIII kWh LIII 685-686 687
Inductive reactive energy consumed L1 kvarhL L1 688-689 68A
Inductive reactive energy consumed L2 kvarhL L2 68B -68C 68D
Inductive reactive energy consumed L3 kvarhL L3 68E-68F 690
Inductive reactive energy consumed LIII kvarhL LIII 691-692 693
Capacitive reactive energy consumed L1 kvarhC L1 694-695 696
Capacitive reactive energy consumed L2 kvarhC L2 697-698 699
Capacitive reactive energy consumed L3 kvarhC L3 69A-69B 69C
Capacitive reactive energy consumed LIII kvarhC LIII 69D-69E 69F
Reactive energy consumed L1 kvarh L1 6A0-6A1 6A2
Reactive energy consumed L2 kvarh L2 6A3-6A4 6A5
Reactive energy consumed L3 kvarh L3 6A6-6A7 6A8
Reactive energy consumed LIII kvarh LIII 6A9-6AA 6AB
Apparent energy consumed L1 kVAh L1 6AC-6AD 6AE
Apparent energy consumed L2 kVAh L2 6AF-6B0 6B1
Apparent energy consumed L3 kVAh L3 6B2-6B3 6B4
Apparent energy consumed LIII kVAh LIII 6B5-6B6 6B7
Active energy generated L1 kWh L1 (-) 6B8-6B9 6BA
Active energy generated L2 kWh L2 (-) 6BB-6BC 6BD
Active energy generated L3 kWh L3 (-) 6BE-6BF 6C0
Active energy generated LIII kWh LIII (-) 6C1-6C2 6C3
Inductive reactive energy generated L1 kvarhL L1 (-) 6C4-6C5 6C6
Inductive reactive energy generated L2 kvarhL L2 (-) 6C7-6C8 6C9
Inductive reactive energy generated L3 kvarhL L3 (-) 6CA-6CB 6CC
Inductive reactive energy generated LIII kvarhL LIII (-) 6CD-6CE 6CF
Capacitive reactive energy generated L1 kvarhC L1 (-) 6D0-6D1 6D2
Capacitive reactive energy generated L2 kvarhC L2 (-) 6D3-6D4 6D5
Capacitive reactive energy generated L3 kvarhC L3 (-) 6D6-6D7 6D8
Capacitive reactive energy generated LIII kvarhC LIII (-) 6D9-6DA 6DB
Reactive energy generated L1 kvarh L1 (-) 6DC-6DD 6DE
Reactive energy generated L2 kvarh L2 (-) 6DF-6E0 6E1
Reactive energy generated L3 kvarh L3 (-) 6E2-6E3 6E4
234
CVM-A1000 - CVM-A1500
Instruction Manual
