Table 71 (Continuation): Modbus memory map: Configuration variables (Configuration of the parameter
customisation screens)
Conguration of the parameter customisation screens
Configuration variable Address
Valid data
margin
Not used 2971 2981 2991 29A1 29B1 0
Not used 2972 2982 2992 29A2 29B2 0
Not used 2973 2983 2993 29A3 29B3 0
Tariff 2974 2984 2994 29A4 29B4 Table 76
Not used 2975 2985 2995 29A5 29B5 0
Not used 2976 2986 2996 29A6 29B6 0
Not used 2977 2987 2997 29A7 29B7 0
(60)
A 0 must be sent in the energy parameters where the consumption or generation option does not exist.
Note: The 80 registers must be written at once (as a group), otherwise it will respond with an
error. They can be read separately.
Table 72:Modbus memory map: Conguration variables (Conguration of the parameter customisation screens).
Conguration of the parameter customisation screens
Configuration variable Address
Valid data
margin
3 parameter screens Screen 1 Screen 2 Screen 3 Screen 4 Screen 5
Parameter 1: Variable 29CC 29DC 29EC 29FC 2A0C Table 74
Parameter 2: Variable 29CD 29DD 29ED 29FD 2A0D Table 74
Parameter 3: Variable 29CE 29DE 29EE 29FE 2A0E Table 74
Not used 29CF 29DF 29EF 29FF 2A0F 0
Parameter 1: Phase 29D0 29E0 29F0 2A00 2A10 Table 75
Parameter 2: Phase 29D1 29E1 29F1 2A01 2A11 Table 75
Parameter 3: Phase 29D2 29E2 29F2 2A02 2A12 Table 75
Not used 29D3 29E3 29F3 2A03 2A13 0
Parameter 1:
(61)
Consumption or Generation
29D4 29E4 29F4 2A04 2A14 0: Consumption
1: Generation
Parameter 2:
(61)
Consumption or Generation
29D5 29E5 29F5 2A05 2A15 0: Consumption
1: Generation
Parameter 3:
(61)
Consumption or Generation
29D6 29E6 29F6 2A06 2A16 0: Consumption
1: Generation
Not used 29D7 29E7 29F7 2A07 2A17 0
Parameter 1: Tariff 29D8 29E8 29F8 2A08 2A18 Table 76
Parameter 2: Tariff 29D9 29E9 29F9 2A09 2A19 Table 76
Parameter 3: Tariff 29DA 29EA 29FA 2A0A 2A1A Table 76
Not used 29DB 29EB 29FB 2A0B 2A1B 0
(61)
A 0 must be sent in the energy parameters where the consumption or generation option does not exist.
Note: The 80 registers must be written at once (as a group), otherwise it will respond with an
error. They can be read separately.
