DESCRIPTION SYMBOL ID OBJECTS OBJECT NAME UNITS
Potencia aparente
trifásica
Three phase aparent
power
kVAIII AI43 AppPw3Ph kVA
Máxima demanda I1 Maximum demand I1 Md (A1) AI44 MaxDemand_A1 A
Máxima demanda I2 Maximum demand I2 Md(A2) AI45 MaxDemand_A2 A
Máxima demanda I3 Maximum demand I3 Md(A3) AI46 MaxDemand_A3 A
Máxima demanda A Maximum demand A A III AI47 MaxDemand_A A
Máxima demanda kW Maximum demand kW kW III AI48 MaxDemand_kW kW
Máxima demanda kVA Maximum demand kVA kVA III AI49
MaxDemand_
kVA
kVA
Analogue Value Object Type
1. Dynamically creatable using BACnet’s CreateObject service? No
2. Dynamically deletable using BACnet’s DeleteObject service? No
3. List of optional properties supported:
4. List of all properties that are writeable where not otherwise required by this standard
5. List of proprietary properties:
Property Identier Property Datatype Meaning
5. List of object identiers and their meaning in this device
Object ID Object Name Description
AV1 MAC_Address MAC
AV2 BaudRate BAUD RATE
AV3 Device_ID DEVICE ID
Device Object Type
1. Dynamically creatable using BACnet’s CreateObject service? No
2. Dynamically deletable using BACnet’s DeleteObject service? No
3. List of optional properties supported: Description, Protocol_Conformance_Class
4. List of all properties that are writeable where not otherwise required by this standard
Object_Name
Max_Master
Max_Info_Frames
Object_Identier
5. List of proprietary properties:
5. List of any property value range restrictions
Property Identier Restrictions
Object_Name < 32 bytes
Object_Identier Device Type only
Number_Of_APDU_Retries 0-255
APDU_Timeout 0-65535 milliseconds
Vendor_Identier 0-65535
Data Link Layer Options (check all that supported):
X MS/TP master (Clause 9), baud rate(s): 9.6, 19.2, 38.4, 57.6, 76.8kB/s
Character Sets Supported (check all that apply):
Indicating support for multiple character set does not imply that they can all be supported simultane-
ously.
X ANSI X3.4
262
CVM-A1000 - CVM-A1500
Instruction Manual
