The following options appear in the lower area:
>
>
<
<
>
<
>
<
Main
menu
Back
Digital
input
Digital
Relay
outputs
Figure 336: Setup menu : relay digital inputs/outputs�
Use the keys and to select the different options.
To conrm the selection, press the key .
7�2�3�1�- Digital inputs�
The operating mode for 8 digital inputs and the parameters for each mode are selected in the
main conguration screen for digital inputs, Figure 337.
The 8 inputs can be congured separately as:
Impulses.
Logic state.
The order for conguring an input is:
1�- Select the operating mode: impulses or logic state.
2�- Select the digital input and congure the appropriate parameters.
268
CVM-A1000 - CVM-A1500
Instruction Manual
