Table 167 ( Continuation) : GSD modules (Module 8)
Mod 8
Odd harmonics voltage Symbol Bytes Address Units
13th Order Harmonic v1 H13 2 0A35 %x100
15th Order Harmonic v1 H15 2 0A37 %x100
L 2
Fundamental Harm. V2_fund 4 0A5B-0A5C Vx100
3rd Order Harmonic v2 H3 2 0A5E %x100
5th Order Harmonic v2 H5 2 0A60 %x100
7th Order Harmonic v2 H7 2 0A62 %x100
9th Order Harmonic v2 H9 2 0A64 %x100
11th Order Harmonic v2 H11 2 0A66 %x100
13th Order Harmonic v2 H13 2 0A68 %x100
15th Order Harmonic v2 H15 2 0A6A %x100
L3
Fundamental Harm. V3_fund 4 0A8E-0A8F Vx100
3rd Order Harmonic v3 H3 2 0A91 %x100
5th Order Harmonic v3 H5 2 0A93 %x100
7th Order Harmonic v3 H7 2 0A95 %x100
9th Order Harmonic v3 H9 2 0A97 %x100
11th Order Harmonic v3 H11 2 0A99 %x100
13th Order Harmonic v3 H13 2 0A9B %x100
15th Order Harmonic v3 H15 2 0A9D %x100
N
Fundamental Harm. Vn_fund 4 0AC1-0AC2 Vx100
3rd Order Harmonic vn H3 2 0AC4 %x100
5th Order Harmonic vn H5 2 0AC6 %x100
7th Order Harmonic vn H7 2 0AC8 %x100
9th Order Harmonic vn H9 2 0ACA %x100
11th Order Harmonic vn H11 2 0ACC %x100
13th Order Harmonic vn H13 2 0ACE %x100
15th Order Harmonic vn H15 2 0AD0 %x100
Module 9
Table 168: GSD modules (Module 9)
Mod 9
Odd harmonics current Symbol Bytes Address Units
L 1
Fundamental Harm. I1_fund 4 0B54-0B55 mA
I1 3th Order Harmonic i1 H3 2 0B57 %x100
I1 5th Order Harmonic i1 H5 2 0B59 %x100
I1 7th Order Harmonic i1 H7 2 0B5B %x100
I1 9th Order Harmonic i1 H9 2 0B5D %x100
I1 11th Order Harmonic i1 H11 2 0B5F %x100
I1 13th Order Harmonic i1 H13 2 0B61 %x100
I1 15th Order Harmonic i1 H15 2 0B63 %x100
L 2
Fundamental Harm. I2_fund 4 0B87-0B88 mA
333
Instruction Manual
CVM-A1000 - CVM-A1500
