Module 4
Table 165: GSD modules (Module 4)
Mod 4
Total tariff Symbol Bytes
Address
kWh
Address
Wh
Units
Tariff 1
Active Energy kwh III 4 500-501 kWh
Active Energy wh III 2 502 Wh
Inductive Reactive Energy kvarhL III 4 503-504 kWh
Inductive Reactive Energy varhL III 2 505 Wh
Capacitive reactive energy kvarhC III 4 506-507 kWh
Capacitive reactive energy varhC III 2 508 Wh
Three-phase apparent energy kVAh III 4 509-50A kWh
Three-phase apparent energy VAh III 2 50B Wh
Generated active energy kWhIII (-) 4 50C-50D kWh
Generated active energy WhIII (-) 2 50E Wh
Inductive active energy kvarLhIII (-) 4 50F-510 kWh
Inductive active energy varLhIII (-) 2 511 Wh
Inductive active energy kvarChIII (-) 4 512-513 kWh
Inductive active energy varChIII (-) 2 514 Wh
Generated apparent energy kVAhIII (-) 4 515-516 kWh
Generated apparent energy VAhIII (-) 2 517 Wh
Module 5
Table 166: GSD modules (Module 5)
Mod 5
THD V / I Symbol Bytes Address Units
V 1 THD ratio THDV1 4 4E-4F %x100
V 2 THD ratio THDV2 4 50-51 %x100
V 3 THD ratio THDV3 4 52-53 %x100
V N THD ratio THDVN 4 54-55 %x100
I 1 THD ratio THDI1 4 56-57 %x100
I 2 THD ratio THDI2 4 58-59 %x100
I 3 THD ratio THDI3 4 5A-5B %x100
IN THD ratio THDIN 4 5C-5D %x100
Module 8
Table 167: GSD modules (Module 8)
Mod 8
Odd harmonics voltage Symbol Bytes Address Units
L 1
Fundamental Harm. V1_fund 4 0A28-0A29 Vx100
3rd Order Harmonic v1 H3 2 0A2B %x100
5th Order Harmonic v1 H5 2 0A2D %x100
7th Order Harmonic v1 H7 2 0A2F %x100
9th Order Harmonic v1 H9 2 0A31 %x100
11th Order Harmonic v1 H11 2 0A33 %x100
332
CVM-A1000 - CVM-A1500
Instruction Manual
