Module 2
Table 161: GSD modules (Module 2)
Mod 2
Powers Symbol Bytes Address Units
Active powers
Active power Kw 1 4 04-05 W
Active power Kw 2 4 14-15 W
Active power Kw 3 4 24-25 W
Inductive reactive powers
Inductive reactive power KvarL 1 4 06-07 var
Inductive reactive power KvarL 2 4 16-17 var
Inductive reactive power KvarL 3 4 26-27 var
Capacitive reactive powers
Capacitive reactive power KvarC 1 4 08-09 var
Capacitive reactive power KvarC 2 4 18-19 var
Capacitive reactive power KvarC 3 4 28-29 var
Apparent power
Apparent power kVA1 4 0A-0B VA
Apparent power kVA2 4 1A-1B VA
Apparent power kVA3 4 2A-2B VA
Module 3
Table 162: GSD modules (Module 3 - Mod 3�1)
Mod 3�1
Average values Symbol Bytes Address Units
Average phase voltage Vn_AVG 4 3C-3D Vx100
Average line voltage Vp_AVG 4 3E-3F Vx100
Average current I_AVG 4 40-41 mA
Table 163: GSD modules (Module 3 - Mod 3�2)
Mod 3�2
Neutral values Symbol Bytes Address Units
Neutral voltage Vn 4 30-31 Vx100
Neutral current In 4 32-33 mA
Current A 3 4 22-23 mA
Table 164: GSD modules (Module 3 - Mod 3�3)
Mod 3�3
Three-phase values Symbol Bytes Address Units
Three-phase active power Kw III 4 42-43 W
Three-phase inductive power KvarL III 4 44-45 var
Three-phase capacitive power KvarC III 4 46-47 var
Three-phase apparent power KvaIII 4 48-49 VA
Three-phase power factor PFIII 4 4A-4B x100
Cos φ three-phase Cos φ III 4 4C-4D x100
331
Instruction Manual
CVM-A1000 - CVM-A1500
