Table 155 (Continuation): GSD modules�
Module Name Bytes ∑
Mod 12 Mod 12
Mod 13 Mod 13 Cos φ 12 12
Module 1
Table 156: GSD modules (Module 1 - Mod 1�1)
Mod 1�1
Phase-neutral voltage Symbol Bytes Address Units
Voltage phase 1 V 1 4 00-01 Vx100
Voltage phase 2 V 2 4 10-11 Vx100
Voltage phase 3 V 3 4 20-21 Vx100
Table 157: GSD modules (Module 1 - Mod 1�2)
Mod 1�2
Phase currents Symbol Bytes Address Units
Current A 1 4 02-03 mA
Current A 2 4 12-13 mA
Current A 3 4 22-23 mA
Table 158: GSD modules (Module 1 - Mod 1�3)
Mod 1�3
Phase-phase voltage Symbol Bytes Address Units
Line voltage L1-L2 V 12 4 36-37 Vx100
Line voltage L2-L3 V 23 4 38-39 Vx100
Line voltage L3-L1 V 31 4 3A-3B Vx100
Table 159: GSD modules (Module 1 - Mod 1�4)
Mod 1�4
Power factor Symbol Bytes Address Units
Power factor PF 1 4 0C-0D x100
Power factor PF 2 4 1C-1D x100
Power factor PF 3 4 2C-2D x100
Table 160: GSD modules (Module 1 - Mod 1�5)
Mod 1�5
Frequency Symbol Bytes Address Units
Frequency (L1) Hx 4 34-35 Hz x100
330
CVM-A1000 - CVM-A1500
Instruction Manual
