14-18
Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-10
Chapter 14 Configuring STP
Configuring Spanning-Tree Features
Beginning in privileged EXEC mode, follow these steps to configure the port priority of an interface.
This procedure is optional.
Note The show spanning-tree interface interface-id privileged EXEC command displays information only
if the port is in a link-up operative state. Otherwise, you can use the show running-config interface
privileged EXEC command to confirm the configuration.
To return the interface to its default setting, use the no spanning-tree [vlan vlan-id] port-priority
interface configuration command. For information on how to configure load sharing on trunk ports by
using spanning-tree port priorities, see the “Load Sharing Using STP” section on page 17-22.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify an interface to configure, and enter interface
configuration mode.
Valid interfaces include physical interfaces and
port-channel logical interfaces (port-channel
port-channel-number).
Step 3
spanning-tree port-priority priority Configure the port priority for an interface.
For priority, the range is 0 to 240 in increments of 16. The
default is 128. The lower the number, the higher the
priority.
Valid priority values are 0, 16, 32, 48, 64, 80, 96, 112, 128,
144, 160, 176, 192, 208, 224, and 240. All other values are
rejected.
Step 4
spanning-tree vlan vlan-id port-priority priority Configure the VLAN port priority for an interface.
For vlan-id, you can specify a single VLAN identified
by VLAN ID number, a range of VLANs separated by
a hyphen, or a series of VLANs separated by a comma.
The range is 1 to 1005 when the SI is installed and 1 to
4094 when the EI is installed.
For priority, the range is 0 to 240 in increments of 16.
The default is 128. The lower the number, the higher
the priority.
Valid priority values are 0, 16, 32, 48, 64, 80, 96, 112,
128, 144, 160, 176, 192, 208, 224, and 240. All other
values are rejected.
Step 5
end Return to privileged EXEC mode.
Step 6
show spanning-tree interface interface-id
or
show spanning-tree vlan vlan-id
Verify your entries.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
