29-8

Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide

78-11380-10

Chapter 29 Configuring Network Security with ACLs

Configuring ACLs

ACL Numbers

The number you use to denote your ACL shows the type of access list that you are creating. Table 29-2

lists the access list number and corresponding type and shows whether or not they are supported by the

switch. The switch supports IP standard and IP extended access lists, numbers 1 to 199 and 1300 to 2699.

Note In addition to numbered standard and extended ACLs, you can also create named standard and extended

IP ACLs by using the supported numbers. That is, the name of a standard IP ACL can be 1 to 99; the

name of an extended IP ACL can be 100 to 199. The advantage of using named ACLs instead of

numbered lists is that you can delete individual entries from a named list.

Table 29-2 Access List Numbers

ACL Number Type Supported

1–99 IP standard access list Yes

100–199 IP extended access list Yes

200–299 Protocol type-code access list No

300–399 DECnet access list No

400–499 XNS standard access list No

500–599 XNS extended access list No

600–699 AppleTalk access list No

700–799 48-bit MAC address access list No

800–899 IPX standard access list No

900–999 IPX extended access list No

1000–1099 IPX SAP access list No

1100–1199 Extended 48-bit MAC address access list No

1200–1299 IPX summary address access list No

1300–1999 IP standard access list (expanded range) Yes

2000–2699 IP extended access list (expanded range) Yes
