Page #490 background image
25-10
Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-10
Chapter 25 Configuring SPAN and RSPAN
Configuring SPAN
This example shows how to configure the destination port for ingress traffic on VLAN 5 by using a
security device that does not support 802.1Q encapsulation.
Switch(config)# monitor session 1 destination interface fastethernet0/5 ingress vlan 5
This example shows how to configure the destination port for ingress traffic on VLAN 5 by using a
security device that supports 802.1Q encapsulation.
Switch(config)# monitor session 1 destination interface fastethernet0/5 encapsulation
dot1q ingress vlan 5
This example shows how to disable ingress traffic forwarding on the destination port.
Switch(config)# monitor session 1 destination interface fastethernet0/5 encapsulation
dot1q
Step 4
monitor session session_number
destination interface interface-id
[encapsulation {dot1q}] [ingress vlan
vlan id]
Specify the SPAN session, the destination port (monitoring port), the
packet encapsulation, and the ingress VLAN.
For session_number, specify 1.
For interface-id, specify the destination port. Valid interfaces include
physical interfaces.
(Optional) Specify the encapsulation header for outgoing packets. If
not specified, packets are sent in native form.
dot1qUse 802.1Q encapsulation.
(Optional) Enter ingress vlan vlan id to enable ingress forwarding
and specify a default VLAN.
Step 5
end Return to privileged EXEC mode.
Step 6
show monitor [session session_number] Verify your entries.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
