Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-10
Chapter 30 Configuring QoS
Configuring Auto-QoS
If you entered the auto qos voip cisco-softphone command,
the switch automatically creates class maps and policy maps.
Switch(config)# class-map match-all
AutoQoS-VoIP-RTP-Trust
Switch(config-cmap)# match ip dscp 46
Switch(config)# class-map match-all
AutoQoS-VoIP-Control-Trust
Switch(config-cmap)# match ip dscp 24 26
Switch(config)# policy-map AutoQoS-Police-SoftPhone
Switch(config-pmap)# class AutoQoS-VoIP-RTP-Trust
Switch(config-pmap-c)# set ip dscp 46
Switch(config-pmap-c)# police 1000000 4096
exceed-action drop
Switch(config-pmap)# class
AutoQoS-VoIP-Control-Trust
Switch(config-pmap-c)# set ip dscp 24
Switch(config-pmap-c)# police 1000000 4096
exceed-action drop
After creating the class maps and policy maps, the switch
automatically applies the policy map called
AutoQoS-Police-SoftPhone to an ingress interface on which
auto-QoS with the Cisco SoftPhone feature is enabled.
Switch(config-if)# service-policy input
AutoQoS-Police-SoftPhone
The switch automatically assigns egress queue usage (as
shown in Table 30-3 on page 30-10) on this interface.
The switch enables the egress expedite queue and assigns
WRR weights to queues 1, 2, and 3. (The lowest value for a
WRR queue is 1. When the WRR weight of a queue is set to 0,
this queue becomes an expedite queue.)
The switch configures the CoS-to-egress-queue map:
• CoS values 0 and 1 select queue 1.
• CoS values 2 and 4 select queue 2.
• CoS values 3, 6, and 7 select queue 3.
• CoS value 5 selects queue 4 (expedite queue).
Because the expedite queue (queue 4) contains the VoIP data
traffic, the queue is serviced until empty.
Switch(config)# wrr-queue bandwidth 10 20 70 1
Switch(config)# no wrr-queue cos-map
Switch(config)# wrr-queue cos-map 1 0 1
Switch(config)# wrr-queue cos-map 2 2 4
Switch(config)# wrr-queue cos-map 3 3 6 7
Switch(config)# wrr-queue cos-map 4 5
Table 30-4 Generated Auto-QoS Configuration
Description Automatically Generated QoS Command Equivalent

Cisco 2950 - Catalyst Switch Specifications

General

Forwarding Rate	6.6 Mpps
Jumbo Frame Support	No
Weight	8.8 lbs (4 kg)
RAM	16 MB
Flash Memory	8 MB
Manageable	Yes
Form Factor	Rack-mountable
Ports	24 Ethernet 10/100 ports
Uplink Ports	2 x 10/100/1000Base-T ports
VLANs	250
MAC Address Table Size	8000
Power Supply	100-240 VAC, 50-60 Hz
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Operating Temperature	0 to 40 °C (32 to 104 °F)
Storage Temperature	-25 to 70 °C (-13 to 158 °F)
Operating Humidity	10% to 85% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
