Chapter 4 Cisco ASR 1000 Series Router SPA Interface Processors (SIPs)
SPA Interface Processor Slot Numbering
Figure 4-3 shows the slot numbering for the shared port adapters on the Cisco ASR 1000 Series SPA
Interface for the Cisco ASR 1006 Router and Cisco ASR 1004 Router.
Figure 4-3 Cisco ASR 1004 Router and Cisco ASR 1006 Router SPA Interface Subslot Numbering
Note The slot numbering for the SPAs on the Cisco ASR 1004 Router is the same as the numbering on the
Cisco ASR 1006 Router.
Cisco ASR 1002 Router
In the Cisco ASR 1002 Router, the Cisco ASR1002-SIP10 supports:
• Three removable half-height SPAs on Bay 1, 2, and 3
• The fourth SPA is a built-in 4xGE SPA on Bay 0 located on the Cisco ASR 1000 Series RP1
Note The shared port adapters on the Cisco ASR1002-SIP10 support online insertion and removal.
However, the Cisco ASR1002-SIP10 in the Cisco ASR 1002 Router is built into the chassis and
is not a field-replaceable unit and does not support online insertion and removal.Figure 4-4
shows the slot numbering for the shared port adapters on the Cisco ASR 1000 Series SPA
Interface for the Cisco ASR 1002 Router.
SPA 0 SPA 1
SPA 2 SPA 3
Front of SIP, horizontal chassis slots
SPA 0 SPA 1 SPA 2 SPA 3
Vertical slot orientation
SPA 0 SPA 1
Double-height SPA
SPA 3
SPA 1
Double-height SPA
116887
SPA 0
SPA 2
