Cisco ASR 1000 Series Hardware Installation Guide

A-1
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
APPENDIX
A
Cisco ASR 1000 Series Router Specifications
This appendix provides router specifications and cable assemblies and pinouts for the cables shipped
with the Cisco ASR 1000 Series Aggregation Services Routers.
This appendix contains the following sections:
• Cisco ASR 1006 Router Specifications, page A-1
• Cisco ASR 1004 Router Specifications, page A-5
• Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco ASR 1002-X Router Specifications,
page A-8
• Cisco ASR 1013 Router Specifications, page A-14
• Cisco ASR 1001 Router Specifications, page A-17
Cisco ASR 1006 Router Specifications
This section lists the specifications for the Cisco ASR 1006 Router.
Table A-1 lists the Cisco ASR 1006 Router physical specifications.
Table A-1 Cisco ASR 1006 Router Specifications
Description Specification
Midplane Connects the Cisco ASR 1000 Series RP1, Cisco ASR 1000 Series ESP, Cisco ASR 1000
Series SPA Interface (SIP), SPAs, and power supplies together in the system
Dimensions (H x W x D) Height = 10.5 in. (25.4 cm)
Width = 17.25 in.(43.815 cm)
Depth = 22.50 in. (57.15 cm)
Weight
• Fully loaded chassis: 109.1 pounds (49.5 kg)
• Only chassis: 25 pounds (11.33kg)
Note Using the Cisco ASR1000-ESP100 instead of the Cisco ASR1000-ESP40 adds 2.1
lbs to the total weight of the router.
Nominal operating temperature
• 41° to 104° F
• 5° to 40° C
