Cisco ASR 1013 Router Overview and Installation
This chapter describes the Cisco ASR 1013 Router and provides the procedures for installing the
Cisco ASR 1013 Router in equipment racks and hardware upgrade process.
This chapter contains the following sections:
• Cisco ASR 1013 Router Description, page 11-1
• Installation Methods, page 11-8
• General Rack Installation Guidelines, page 11-8
• Guidelines for Equipment Rack Installation, page 11-10
• Attaching the Rear Rack-Mount Brackets, page 11-11
• Rack-Mounting the Cisco ASR 1013 Router, page 11-13
• Attaching the Cable-Management Bracket, page 11-21
• Attaching a Chassis Ground Connection, page 11-24
• Connecting the Shared Port Adapter Cables, page 11-25
• Connecting the Console and Auxiliary Port Cables, page 11-26
• Connecting Power to the Cisco ASR 1013 Router, page 11-27
• Connecting a Terminal to the Cisco ASR 1000 Series RP Console Port, page 11-35
• Connecting the System Cables, page 11-36
• Auxiliary Connection, page 10-314
• Attaching Cable Retention Bracket on AC Power Supply, page 11-36
Cisco ASR 1013 Router Description
The Cisco ASR 1013 Router supports full-width card modules. It is designed with a single midplane with
connectors on one interface midplane. The Cisco ASR 1013 Router supports:
• Up to 6 ASR1000-SIP40G shared port adapter modules
• Up to 24 shared port adapters (SPAs) and up to six SIPs
• Two embedded services processors (Cisco ASR1000-ESP40, Cisco ASR1000-ESP100, or Cisco
ASR1000-ESP200)
• Cisco ASR1000-RP2 route processor
